Aventure M is the perfect blend of rugged capability, performance, and technology to help you explore further than ever before. With maticulously designed frame geometry, a 80mm suspension fork, and 4.0" tires, there's nowhere the Aventure M can't take you. The Aventon A100 mid drive motor provides enough torque and power to conquer any terrain, giving you a responsive ride feel that can be easily customized with Ride Tune capabilities. With Aventon's electronic autoshift functionality ensuring you're always in the right gear at the right time, you can focus solely on the making it to the next mountain peak. ACU technology brings a host of connectivity and added security features including GPS† tracking and an integrated lock, while the updated display brings you important metrics like torque, cadence, and power to help you maximize every ride. No matter where you want to go, Aventure M will get you there.
General Info
Total Weight Limit: 400 lbs
Rider Height: R: 5'3" - 5'10" , L: 5'10" - 6'4"
Ebike Class: Class 1 (Aftermarket Throttle Available for Class 2 Conversion. Can also be converted to Class 3)
Water Resistance: Bike - IPX6 // Motor - IP67
Ideal Use: All-Terrain Performance
Pedal Assist: 3 Levels (with Ride Tune Customization)
Fork: Aventon/Zoom Suspension Fork, 80mm travel, with lockout
Ebike System
Motor: Aventon a100 mid-drive. 36v, 250W (sustained), 750W (peak), 100NM torque. IP67 rating
Battery: Removable Internal Lithium-ion. 36V, 20Ah, 733Wh, LG 21700 cells
Throttle: Aftermarket Throttle Available for Purchase
Sensors: Double Sided Torque Sensor Integrated in Motor
Charger: 36V Output: 42V/ 4A
Charging time from 0% to 100%: 5 hours
Lights: Integrated front and rear running lights (no brake lights)
Components
Front Brake: SRAM DB4 Hydraulic Disc Brakes w/o cutoff
Rear Brake: SRAM DB4 Hydraulic Disc Brakes w/o cutoff
Front Brake Rotor: Sram G2 200mm 6-Bolt
Rear Brake Rotor: Sram G2 200mm 6-Bolt
Rear Derailleur: Shimano Cues 10-Speed
Chain: 9/10/11 Speed 124L
Cassette: Shimano Cues 10-Speed 11-39T
Pedals: 9/16" Alloy Platform
Seatpost: 30.9mm Aventon Suspension Seatpost with 50mm travel
Handlebars: Aluminum 31.8mm, 720mm
Grips: Aventon Lock on grips
Technical Overview
Aventure M comes out of the box as a Class I ebike, with pedal assist. An Aventon throttle can be purchased and easily installed on Aventure M to convert to Class 2. Aventon ebikes are built to the IPX6-rated standard. An IPX6 rating means the bike is protected against high-pressure water streams from any angle. This provides strong water resistance, so you can confidently ride in heavy rain or through puddles and mud. However, IPX6 does not mean waterproof—Aventon ebikes are not designed for full submersion. Avoid using a pressure washer or sprayer to clean your ebike, as pressurized water can still damage components.
